Dahua DH-HAC-B1A51P-U-IL-A — Analog Camera

Description

The Dahua DH-HAC-B1A51P-U-IL-A is a 5MP Smart Dual Light HDCVI bullet camera designed for higher-resolution analog surveillance. It combines IR and warm-light illumination with flexible CVI/TVI/AHD/CVBS output and a built-in microphone.

Key Features

• 5MP 2880 × 1620 resolution
• Smart Dual Light: IR up to 30 m and warm light up to 20 m
• Built-in microphone
• 2.8 mm / 3.6 mm / 6 mm fixed-focal lens options
• CVI / TVI / AHD / CVBS switchable output
• DWDR, BLC/HLC and 2D NR
• IP67 protection

Specifications

• Image sensor: 5MP CMOS
• Maximum resolution: 2880 × 1620
• Lens: Fixed-focal, 2.8 mm / 3.6 mm / 6 mm
• Illumination: IR 30 m / warm light 20 m
• Audio: Built-in microphone
• Video output: CVI / TVI / AHD / CVBS via BNC
• Frame rate: Up to 5MP @ 25 fps PAL / 30 fps NTSC depending on format
• Power: 12 VDC ±30%
• Maximum power: 4.0 W with warm light on
• Operating temperature: −40°C to +60°C
• Protection: IP67
• Installation: Wall / ceiling / vertical pole mount
